Widgets and Custom Components

GLG Toolkit provides the following pre-built collections of widgets:

• Controls: Dials, Meters, Custom Buttons and Toggles, Indicators, Switches, Knobs, Sliders and other controls.
• Avionics Controls: Collection of avionics meters and gauges.
• Process Control Symbols: Tanks, vessels, columns, valves and other process-control symbols.
• Electrical and Electronic Circuit Symbols: Switches, relays, transformers, active and passive electronic circuit components, as well as other miscellaneous electrical components.
• Real-Time Charts: High-performace charts optimized for real-time display of large data sets.
• 2D Graphs: Bar, Line, Filled Line, Scatter, Pie and other 2D graphs.
• 3D Graphs: 3D versions of the graphs as well as the 3D Surface graph.
• Special Widgets: Palettes, Text Fields, Spinners, Axes, Layout Templates and other building blocks for creating specialized custom drawings.

Custom widgets can be built using the Professional or Enterprise Editions of the Graphics Builder and integrated into the Builder's palettes. Generic Logics provides services for building custom widgets. Contact Generic Logic for more information.

Controls Widget Set

Dials, Meters, Custom Buttons and Toggles, Indicators, Switches, Knobs, Sliders and other controls.

Dials and Meters

Sliders and Joysticks

Toggles and Switches

Value Display Widgets

Push Buttons

Toggle Buttons

Knobs

State Indicators, Date and Lat/Lon

Linear Gauges

Specialty Gauges

Avionics Widget Set

Avionics meters and gauges, including artificial horizon gauge.

Process Control Symbol Set

Includes the standard process control symbols with integrated dynamic behavior.

Tanks, Columns and Heat Exchangers

Valves

Process Control Equipment

Motors, Pumps and Fans

Process Control Gauges and Indicators

Pipes and Lines

3D Pipes

Electrical and Electronic Circuit Symbols

Includes the standard electrical and electronic circuit symbols, as well as relays and switches with integrated dynamic behavior.

Electric Switches and Relays

Transformers and Inductors

Resistors, Capacitors and Diodes

Transistors, Gates and Amplifiers

Miscellaneous Electrical Components

Real-Time Chart Widget Set

Real-Time Sweep Chart Widget Set

2D Graph Widget Set

Bar, Line, Filled Line, Scatter, Pie and other 2D graphs.

3D Graph Widget Set

3D versions of the Bar, Packed Bar, Stacked Bar and other graphs.

Special Widgets

Includes graph legends and axes, palettes, resource browser and a text input widget.

Menus and CheckBoxes

Spinners and Miscellaneous Input Widgets

Axes and Rulers

Tabs Widgets

Layout Widgets

Miscellaneous Special Widgets
